Impact Moles


To enquire about Impact Moles please call the number below or fill in our short enquiry form:

telephone icon  01226 785 722

Make an Enquiry

Download PDF

Overview

The Essig ‘Smart’ IP range are the only moles on the market which inform the operator when servicing is required. Typical service intervals are between 6 to 8 months. Smaller launch / reception pits are an advantage with the shorter length ‘Smart’ moles. Our range consists of sizes from 45mm to 530mm.

  • 2 Year Warranty
  • Rugged and Reliable
  • Unrivalled Power
  • Finance Available

Specifications

IPM Type
dia in mm
Length
mm
Weight
kg
Air Consumption
m3 at bar
Impact
per min
Upto max
dia
Expanders
45 ‘S’ 770 8 1 440 DN32
45 1000 9 1 330 DN32
55 ‘S’ 950 12 1 410 DN40
55 1200 16 1 330 DN40
75 ‘S’ 1050 22 1 420 DN63
75 1500 29 1 330 DN63
95 ‘S’ 1200 42 2 520 DN80 120,130,140
95 1500 50 2 400 DN80 120,130,140, 160,175
110 1500 72 2 400 DN90 140,160,175
130 1600 90 3.5 400 DN110 150,160,180,200
145 1850 140 5 400 DN125 180/200
