To enquire about Hercu Moles please call the number below or fill in our short enquiry form:
Hercu Pneumatic is one of the largest European manufacturer’s of Impact Moles. Enjoying over 50 years of experience you can trust the H.P. brand. The Hercu range consists of sizes from 45mm to 550mm, including moving head machines. Our piling machines are unrivalled in their field for power and reliability.
| IPM Type dia in mm |
Length mm |
Weight kg |
Air Consumption m3 at bar |
Impact per min |
Upto max dia |
Expanders |
|---|---|---|---|---|---|---|
| HP45 | 955 | 7.8 | 0.8 | — | — | — |
| HP55 | 1200 | 14 | 1.2 | — | — | — |
| HP55R | 1250 | 15 | 1 | — | Up to OD40 | — |
| HP65 | 1350 | 24 | 1.2 | — | — | — |
| HP70 | 1350 | 28 | 1.2 | — | — | 100 |
| HP70R | 1470 | 34 | 1.7 | — | Up to OD50 | 100 |
| HP75M | 1470 | 33.5 | 1.7 | — | — | — |
| HP75RM | 1470 | 34 | 1.7 | — | Up to OD63 | — |
| HP95 | 1515 | 54 | 2.3 | — | — | 160, 220, 260, 300 |
| HP95KR | 1250 | 45 | 2 | — | — | — |
| HP135 | 1880 | 128 | 2.8 | — | — | 260, 300, 300 |
| HP135K | 1500 | 90 | 3.5 | — | — | — |
| HP135R (PREDATOR) | 1780 | 112 | 2.6 | — | — | — |
| HP160 | 1780 | 140 | 4 | — | OD80 – 324 | — |
| HP160L | 2050 | 190 | 5.3 | — | — | 400, 450, 500, 550 |
| HP185 | 2150 | 260 | 5 | — | — | 450, 500, 550 |
| HP240ET | 1700 | 360 | 5 | — | OD219 – 600 | — |
| HP240LV (on request) | — | — | — | — | — | — |
| HP260 | 2300 | 620 | 8 | — | — | — |
| HP375 | 2700 | 1550 | 12 | — | OD500 – 1200 | — |
| HP550 | 3000 | 4000 | 20 | — | OD600 – 1400 | — |
